Micsig TO202 Touch tablet Oscilloscope

$569.00



Request a Quotation
















No Substitutes

Add me to your email list for monthly specials.
(private list no 3rd party use)
Technical Specifications

Bandwidth
200.00MHz

Channels
2

Sample Rate
1GSa/s

Extra Specifications
18Mpts


Product Description

Micsig TO202


Basic Operation






Appearance|Feature








Function




Deeper memory depth

Not only observe general waveform but also can find every waveform detail.
TO*** model standard memory depth is 18 Mpts(90M is optional)and TO***A model standard memory depth is 90 Mpts.






       Up to 500K wfms/s waveform capture rate

        tBook series waveform capture rate can be upgraded to 250,000wfms/s or             500,000wfms/s.Improve the probability of catching the abnormal  signal to             90%.The higher capture rate, the shorter dead time ofwaveform,
        abnormal  signals can be caught fast and accurately,which gives you the               highest probability of capturing random and infrequent events.




 Automatic Measurment

Swipe out measurement  menu,tap to select or cancel the meaurement         icon,it makes operation more convenient.


      Storage

       No limitation to storage waveform,you can name the waveform by typing the          soft keyboard.




Zoom

Flick left or right lightly to locate your wanted waveform, it gets your waveform clearer quickly.




       Reference waveform

 You can set 4 sets reference waveform to compare,which makes you work             easier.



Math Functions

5 Math operator:+,-,*,/,FFT.FFTcan add Rectangle,Hamming,Hanning,
Blackman-Harris window function.




       Cursor

        Tap cursor icon to open or close cursor function,tap to select or cancel                 vertical or horizontal cursor line,then flick longer cursor line screen left
         or right to fix your wanted waveform position easily.





Mouse Operation

Abundant operation,exept for multi-touch,user can operate the oscilloscope by mouse connected with USB port. Mouse operation brings you one more option when measuring.


     Bigger capacity Battery

      Battery is optional ,we provide big capacity battery to meet your longer                    battery life.



Operation Protection

Tap the right corner lock to open or close finger operation,it makes your work more safe.



Tablet Oscilloscope tBook Series Specification


    18Mpts
Model   TO102
 TO104
TO102A
 TO104A
TO152
 TO154
  TO152A
  TO154A
TO202
TO204
TO202A
TO204A
Bandwidth100MHz100MHz150MHz150MHz200MHz200MHz
Risetime<=3.5ns<=3.5ns<=2.3ns<=2.3ns<=1.75ns<=1.75ns
Real time
sampling rate
1GSa/s2GSa/s1GSa/s2GSa/s1GSa/s2GSa/s
Memory depth18Mpts90Mpts18Mpts90Mpts18Mpts90Mpts
Waveform capture rate250,000wfm/s500,000wfm/s250,000wfm/s500,000wfm/s250,000wfm/s500,000wfm/s
Channels      2/4
Display screen    10.1"TFT LED Multi point touchalble capacitive screen,Resolution:1024*600
Operation     Mouse,Multi-touch:tap,swipe,pinch
Time base range    2ns/div to 1000s/div for TO***model, 1ns/div to 1000s/div for TO***A model
Vertical resolution     8bit
Vertical Scale     2mV/div to 5V/div
Triggger types    Edge,Pulse,Logic
Automatic measurements    Period, Frequency, Risetime, Falltime, Delay, PDC, NDC, PPW, NPW, BPW, POS, NOS, Phase, PKPK, Amp., Height, Low, Max, Min, RMS,
    CRMS, Mean, CMean
Math operation     +,-,*,/,FFT
FFT window function     Rectangular, Hamming, Hanning, Blackman
I/o port     USB Host, USB Device
Built-in storage     4G
Dimensions and weight     275mm*210mm*60mm,1770g




Standard Accessories


ItemDescription
USB CableConnect scope with PC
ProbeStandard passive, bandwidth and quantity depend on model
Power adapterFor charging
USB calibration connect boardProbe compensation
DocumentsProduct Quick Guide, Safety Information,Packing List, Calibration Certificate, Quick Start
